Honda PCX160 vs Yamaha Nmax (2018-2019) Comparison

Engine & Performance

Displacement	156.9 cc	155 cc
Maximum Power	15.8 hp	14.88 hp
Valves Per Cylinder	4	4
Engine Type	Single Cylinder, 4 Valves, 4-Stroke, Liquid Cooled Engine	4-Stroke, SOHC
Injection Type	Fuel Injection	--
Compression Ratio	12:01	10.5:1
Bore X Stroke	60 mm x 55.5 mm	58 mm x 58.7 mm
Exhaust Pipes	Single Exhaust	Single Exhuast
No. Of Cylinder	1	1
Drive Type	Belt Drive	Belt Drive
Clutch Type	Automatic, Centrifugal, Dry Type	Dry, Centrifugal Automatic
Maximum Torque	14.7 Nm	14.4 Nm
No. Of Strokes	4-Stroke	4-Stroke
Cooling System	Liquid Cooled	Liquid Cooled
Fuel Tank Size	8.1 L	6.6 L
RPM at Maximum Torque	6500 rpm	6000 rpm
RPM at Maximum Power	8500 rpm	8000 rpm
Valve Configuration	--	SOHC
Lubrication System	--	Wet Sump
Top Speed	--	121 kmph
Fuel Economy	--	35 kmpl

View All

Dimension

Category	Scooter	Scooter
Kerb Weight	132 kg	--
Seat Height	764 mm	765 mm
Wheel Base	1313 mm	1350 mm
Height	1123 mm	1115 mm
Seating Capacity	2 Seats	2 Seats
Length	1936 mm	1955 mm
Ground Clearance	135 mm	135 mm
Width	742 mm	740 mm
Oil Tank Capacity	0.8 L	1.0 L
Dry Weight	--	127 kg

View All

Fuel & Ignition

Ignition System	Full Transistorized	TCI
Start Option	Electric	Electric
Fuel Type	Petrol	Petrol
Fuel Supply System	PGM-FI	Fuel Injection

Gear & Transmission

Transmission Type	CVT	Automatic
Gear Box	Variable Speed	Variable Speed

Wheels & Tyres

Rear Wheel Size	R13	R13
Rear Tyre	130/70 R13	130/70 R13
Tyre Type	Radial, Tubeless	Radial, Tubeless
Front Wheel Size	R14	R13
Front Tyre	110/70 R14	110/70 R13

Chassis & Suspension

Front Suspension	Telescopic	Telescopic Fork
Rear Suspension	Dual Rear Suspensiton	Swing Arm

Electrical

Battery Capacity	5 Ah	--
Motor Type	--	No
Pack Voltage	--	No
Pack Capacity	--	No
Power Pack	--	No
Pack Life	--	No
Battery Charge Time	--	No
Range Highway	--	No
Range City	--	No
Charger Type	--	No
Input	--	No

View All

Safety & Security

ABS	No	No
Pass Switch	Yes	Yes
Back Rest	No	No
Stability Control	No	--
Traction Control	No	--
Launch Control	No	No
Leg Guards	No	--
Wheel Lock Front/back	No	No
Riding Modes	Street, Road Street, Road	Street Street
Side Reflectors	No	Optional Optional
Engine Check Warning	Yes	--
Shutter Lock	--	Optional Optional
Central Locking	--	Optional Optional

View All

Console

Odometer	Digital Digital	Yes
Fuel Gauge	Digital Digital	Digital Digital
Tachometer	No	Yes
Tripmeter	Yes	Yes
Navigator	No	No
Display Screen	Yes	Yes
Speedometer	Digital Digital	Yes
Side Stand Indicator	--	Yes

View All

Chassis & Suspension

Body Frame Type	Double Cradle Double Cradle	Underbone Underbone
Seat Type	Dual Straight Dual Straight	Straight Seat Straight Seat
Side Wings	Yes	Yes
Chrome Garnish	Yes	--

Electrical

Head Lamp	LED LED	LED LED
Tail Lamp	LED LED	LED LED
Battery Voltage	12 V 12 V	12 V 12 V
Adjustable Headlights	Yes	Yes
Indicator Light	Yes	Yes
Accessory Outlet	Yes	--

View All

Brake

Rear Brake	Disc Disc	Disc Disc
Front Brake	Disc Disc	Disc Disc

Differentiating Features

Additional Features	Smart Key System Smart Key System	--
Height Adjustable Seats	No	No
Cruise Control	No	No
